Model Specifications


Specifications XD270 XD310 XD410 XD500
Max Torque 259,803 Nm 304,646 Nm 398,602 Nm 480,458 Nm
Max Pressure Do not exceed 240 bar @ 380 lpm Do not exceed 240 bar @ 380 lpm Do not exceed 240 bar @ 380 lpm Do not exceed 240 bar @ 380 lpm
Max Flow Do not exceed 380 lpm @ 240 bar Do not exceed 380 lpm @ 240 bar Do not exceed 380 lpm @ 240 bar Do not exceed 380 lpm @ 240 bar
Max Power Do not exceed 150 Kw Do not exceed 150 Kw Do not exceed 150 Kw Do not exceed 150 Kw
Motor Radial Piston Radial Piston Radial Piston Radial Piston
PRV Included Included Included Included
ECV Included Included Included Included
Diggalign Optional Optional Optional Optional
Overall Length 2410 mm 2410 mm 2410 mm 2410 mm
Diameter 820 mm 820 mm 820 mm 820 mm
Weight 2878 kg 2878 kg 2878 kg 2878 kg
Std Output Shaft 200 mm Square 200 mm Square 200 mm Square 200 mm Square
Australia's leading machinery attachment manufacturer est. 1981
