Specifications | PD3 | PD4 | PD5 | PD6 |
---|---|---|---|---|
Rec Flow Range | 45-75 Ipm | 55-85 Ipm | 60-95 Ipm | 70-115 Ipm |
Max Torque | 3544 Nm | 4448 Nm | 5151 Nm | 5596 Nm |
Motor | 2K Geroler | 2K Geroler | 2K Geroler | 2K Geroler |
Pressure Valve Fitted | Optional | Optional | Optional | Optional |
Energy Control Valve | N / A | N / A | N / A | N / A |
Case Drain Required | No | No | No | No |
Max Pressure | Do not exceed 240 bar @ 60 lpm | Do not exceed 240 bar @ 60 lpm | Do not exceed 240 bar @ 60 lpm | Do not exceed 240 bar @ 60 lpm |
Max Flow | Do not exceed 115 lpm @ 130 bar | Do not exceed 115 lpm @ 130 bar | Do not exceed 115 lpm @ 130 bar | Do not exceed 115 lpm @ 130 bar |
Max Power | Do not exceed 25 Kw (34 hp) | Do not exceed 25 Kw (34 hp) | Do not exceed 25 Kw (34 hp) | Do not exceed 25 Kw (34 hp) |
Overall Length | 579 mm | 579 mm | 579 mm | 730 mm |
Diameter | 240 mm | 240 mm | 240 mm | 240 mm |
Weight (no frame / hitch) | 57 kg | 58 kg | 67 kg | 89 kg |
Std Output Shaft | 65 mm Round | 75 mm Square | 75 mm Square | 75 mm Square |
Swing Control | Optional | Optional | Optional | Optional |
Diggalign | Optional | Optional | Optional | Optional |
Halo | Optional | Optional | Optional | Optional |
Rec Auger | 4 Series | 4 Series / 6 Series | 6 Series | 6 Series |
Max Auger Dia Clay / Shale | 600 mm | 750 mm | 900 mm | 900 mm |
Max Auger Dia Earth | 750 mm | 900 mm | 1000 mm | 1000 mm |
